Specification of the Twin screw extruder:
1. This kind of twin screw extruder of SJSZ Series Conic Twin Screw Extruder with appropriate screws, dies and other auxiliaries can directly convert thermoplastic especially WPC powder into BOARD.
2. Thetwin screw extruder can Provide function of modifying and pelleting.
2. Thetwin screw extruder can Provide function of modifying and pelleting.
3. The twin screw extruderis our main product.
Machine features:
Machine features:
1. This machine can produce sheets,boards ,plates directly from PVC,WPC powder.
2. There are two kinds of electric controlling systems for this extruder, common instrument control system and computer control system.
3. For chief driving methods, direct current timing and converted frequency control timing are available.
4. It exquisitely designed screw and barrel have perfect plasticization effect.
5.The electric control system adopts the most advanced technology and there is an alarming system for every subsection failure.
6. It is convenient to examine and repair.
7. The high-performance distribution system for torque deceleration is wearable and easy to maintain
ITEM | Motor power | Composition | Dimension |
SJSZ80/156 Concical twin screw extruder | 75Kw | Extruder , head die mould , feeding system, constant temperature control system , vacuum exhausting unit | 4750mm×1550mm ×2460mm |
vacuumCalibration table | 7.5Kw | 4 Couples calibration plates | 1500mm×500mm |
Cooling bracket | 2sets trimming knives | Φ70mm x 1500mm | |
Hual-off Unit | 7.5Kw | 6 couples cylinder clamping and loosening | Φ260mm x 1600mm |
Cutting unit | 6Kw | The auto saw cutter the dust collection device | |
Stacker | BFL-1220 | ||
Electrical control panel | ABB frequency converter, Simens contactor ,RKC Japan | ||
Mould | T-die with flange |
