Specifications:
Transmitter | Volume | 53*34*19mm |
Channel | 4/8 adjustable | |
Voltage/Current | 8V/12V/250mA | |
Operation Temperature | -20 to +60 centigrade | |
Frequency | 2.3-2.5GHz | |
Power | 700 mW 28dBm | |
Transmission distance | 150M-500M(in eye sight) | |
Video output | 1Np-p | |
Audio/Video input port | AV(RCA) | |
Receiver | Volume | 135*80*21mm |
Operation Temperature | -20 to +60 centigrade | |
Voltage/Current | 9-12V/250mA | |
Frequency | 2.3-2.5GHz | |
Sensitivity | -85dBM | |
Audio/Video output port | AV(RCA) | |
Accessories | Power adapter | 2 pcs |
3dBantenna | 2 pcs | |
AV cable | 2 pcs | |
User manual | English manual 1 pcs |
Channel and Frequency:
TX CH | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
RX CH | 01 | 02 | 03 | 04 | 05 | 06 | 07 | 08 |
MHz | 2414 | 2432 | 2450 | 2468 | 2370 | 2390 | 2490 | 2510 |
Notice:
For better reception, please make sure that the transmitter and the receiver are placing at least 5 feet above ground. Distance affected by the nature of environment such as noise, weather, traffic, building, trees ... etc.
Antenna must be attached on the transmitter before power up. Otherwise, the transmitter will be burned out because the excess power cannot be released by the antenna.
Antenna must be attached on the transmitter before power up. Otherwise, the transmitter will be burned out because the excess power cannot be released by the antenna.
