V-Bank HEPA filter
V-Bank design could make filtration area big, life-span long and resistance low.
V-Bank design could make filtration area big, life-span long and resistance low.
The frame is selective. Galvanized steel and Stainless steel are available.
It has a installation flange with thickness of 25mm.
The highest temperature is 80oC when it work continuously.
Filter efficiency: H11, H13, H14 (EN1822).
V-Bank design could make filtration area big, life-span long and resistance low.
V-Bank Secondary filter without separator, choose no flange?s design but have big air volume.
Dimension (W*H*D)(mm) | NO. of packs | air flow (m3/h) | Media area (m2) | holding dust (g) | primary resistance (by 0.5m/s) | final resistance | Efficiency |
285*285*295 | 2 | 700 | 5.7 | 380 | <=220Pa | 440Pa | 95%-99.9995% @0.3um |
595*595*295 | 3 | 2100 | 17.8 | 1180 | <=220Pa | 440Pa | |
595*595*295 | 4 | 2700 | 23.8 | 1570 | <=220Pa | 440Pa | |
610*610*295 | 5 | 3500 | 30.4 | 2010 | <=220Pa | 440Pa | |
915*610*295 | 6 | 4200 | 36.5 | 2410 | <=220Pa | 440Pa |
