This pure sine wave inverter instantly convert low voltage DC power to high voltage AC household power.With innovative design and super efficiency that is widely applied for power tools,home appliance,offi equipment,portable equipment and ect.You can use in many places,such as cars,trucks,boats,solar system,wind generator,laptop,cam corder.cell phone,PDAS and so on.
Basic technic data:
Model | CTP-300W | |
Input | DC Voltage | 12V /24V / 48V |
Voltage Range | 11-15V DC or 22-30VDC or 42-66VDC | |
No Load Current Draw | <0.4A | |
Efficiency | > 85% | |
DC Connector | Cables With Clips or Car Adaptor | |
Output | AC Voltage | 100/110/120VAC or 220/230/240 VAC |
Continuous Power | 300W | |
Surge Power | 600W | |
Waveform | Pure Sine Wave | |
Frequency | 50Hz or 60Hz | |
| THD | <3% | |
Protection | Low Voltage Alarm | DC10.2-10.8V or20.4 or40.8 |
Low Voltage Shut Down | 9.5DC or 19.5DC or38.5 | |
Over Load | Shut Off Output | |
Over Voltage Shut Down | 15.5V or 30.5V or 61.2V | |
Over Thermal | Shut Off Output Automatically | |
Fuses | Short Circuit | |
Environment | Working Temperature | Between -10 and +50 |
Working Humidity | 10%~90%RH | |
Storage Temperature | Between -20 and +50 | |
Package | Machine Size(mm) | 200*118*62mm |
Packing Size(mm) | 25*12*6.6cm | |
Net Weight(kg) | 1.3 | |
Gross Weight(kg) | 1.4 | |
Packing Mode | Carton | |
Other | Start | Soft Start |
Cooling Ways | Cooling Fan | |
Features:
1.CE &ROHS,LVD.EMC
2.Output voltage:AC100V/110V/120V or 220v/230v/240v (Optional)
3.Input voltage:DC12V/24V/48V
4.Output wave form:Pure sine wave
5.Frequency:50HZ/60HZ
6.Continuous output power:300w
7.Peak power:600w
8.Max efficiency to 92%
10.Low voltage,overload voltage,short circuit ,over temperature protection.
