Characteristics
Ø Aramid yarn as strength member cable has excellent tensile strength.
Ø Compact structure with high fiber density, good performance of flexibility and crush resistance
Ø The jacket anti-corrosion, anti-water, anti-ultraviolet radiation, flame-retardant and harmless to environment
Ø All dielectric structure design, without electromagnetic induction effect
Ø Scientific design with serious processing art.
Specification
Fiber Type | G652D,G657A1,G657A2,OM1,OM2,OM3,OM4 | ||||
Fiber count | 4 | 6 | 8 | 12 | |
OD(D*H(mm)±0.3mm) | 3.5*2.5 | 3.8*2.5 | 4.5*2.5 | 5.0*2.5 | |
Max. tensile Strength (N) | Short-term | 150 | |||
Long-term | 80 | ||||
Min. Bending Radius (mm) | Dynamic | 60 | |||
Static | 30 | ||||
Min/Max.Crush Resistance (N/100mm2) | 200/1000 | ||||
Temperature range | PVC: -20°C ~+90°C ;LSZH:-20°C ~+70°C | ||||
