Detailed storage cages Description
Mesh containers are the perfect option for companies that prioritize durability, efficiency, and sustainability. They offer a variety of advantages to the industry, including their low maintenance cost. These containers are made from durable and high-quality materials, allowing them to with stand heavy usage over extended periods of time. They are also lightweight and easy to transport, making them ideal for a variety of applications. With the ability to stack, they are a reliable choice for efficient packing and storage. Furthermore, mesh containers are eco-friendly and recyclable, making them an eco-conscious and cost-effective option for your business. If you are searching for a reliable storage and transportation solution, wire containers are a smart investment that is sure to pay dividends in terms of financial savings, practicality, and sustainability.
Wire container:
1.It is made of high quality steel materials and formed by cold harden welding. It has big strength, good load capability and four folded layers. 3D object is achieved. Load capability of different types of storage shelves: 0.8T to 2.0T.
2.Folding structure makes loading, revolving and storing much convenient.
3,It is easy to managing.
4,It can be accumulated to save space when it is not used.
5.The surface is zinc plated, so it is beautiful and durable.There is no pollution in every process.
6.It is proper for moving work of fork man crane, traveling crane, lifter, trolley, and hydraumatic pallet truck.
7,The goods can be easily accessed because the gate can be open.
8.It is in accordance with international standards, and can be used with containers.
9,It is also the replacement of wooden cases.
10,It can be made according to your requirements
CODE | EXTERNAL DIMENSIONS | INTERNAL DIMENSIONS | WIRE DIA. | MESH PITCH | CAPACITY (UDL) | STACKING |
001 | 1000L x 800W x 840mm ht 40"L x 32" W x 33" ht | 960L x 760W x 700 mm ht | 6.0 mm | 50 x 50 | 1500 kgs | 1 + 3 |
002 | 1000L x 800W x 840mm ht 40"L x 32" W x 33" ht | 960L x 760W x 700 mm ht | 6.0 mm | 50 x 100 | 1000 kgs | 1 + 3 |
003 | 1000L x 800W x 500mm ht 40"L x 32" W x 20" ht | 960L x 760W x 360 mm ht | 6.0 mm | 50 x 50 | 750 kgs | 1 + 3 |
004 | 1200Lx1000Wx 890mm ht 48''L x 40''W x 35'' ht | 1160Lx960Wx 750 mm ht | 6.0 mm | 50 x 50 | 1500 kgs | 1 + 3 |
005 | 1200Lx1000Wx 890mm ht 48''L x 40''W x 35'' ht | 1160Lx960Wx 750 mm ht | 6.4 mm | 50 x 100 | 900 kgs | 1 + 3 |
006 | 800L x 600W x 640mm ht 32''L x 20''W x 22'' ht | 760Lx560Wx 500 mm ht | 6.4 mm | 50 x 50 | 800 kgs | 1 + 3 |
007 | 800L x 500W x 540mm ht 32''L x 20''W x 22'' ht | 760Lx460Wx 400 mm ht | 5.0 mm | 25 x 50 | 500 kgs | 1 + 3 |
FAQ:
1, What is the material being used for your products?
---Mild steel Q235, Q195
2, How are the goods being packed?
---Plastic banding + Stretch film wrapped, palletized for easy loading and unloading with standard
forklift truck or pallet jack.
3, What is the payment terms I can get?
---TT or L/C at sight, DP, etc
4, What kind of finish do you provide for your goods?
---A.Electro-galvanized/Zinc plated: the zinc serves as a sacrificial anode( indoor storage)
B.Hot dip galvanized: it forms a coating of corrosion-resistant zinc
(indoor/outdoor and cold storage)
C.Powder coating: a type of coating that is applied as a free-flowing, dry powder (indoor/outdoor storage)
5, I like your design, but is custom size available?
---Yes, we do custom products and projects.
6, I would like to have my own design products and qty is not that big, is it ok?
Yes, we can go with your custom design, no matter small or big qty, however, pls understand the cost will be different.
7 I don't have a drawing or picture available for the custom products, could you design it for me?
--Yes, we can make the best suitable design for you but do need to know the details, such as
a) dimension b) loading capacity c)stackability d)operation environment
8 What is the minimum quantity I can order?
--1x20'GP - quantity is variable depending on the size
9 What is your average production lead time?
--3-4 weeks against formal order and deposit.
10 Do I get any guarantee from your company?
-3~10 years warranty in the case that
A) Proper handling during operation, correctly forklift handling while stacking/unstacking
B) Overloading is prohibited
C) Environment request indoor, dry, and not humid circumstance, do not contact with any corrosive chemical material (for zinc plated and powder coated products, no limitation for hot-dip galvanized)
